What is Issue?
When working on D365 CRM, Some time user wants to download file from SharePoint, OneDrive or CRM Notes itself. So how you will do it in shortest way?
The Reason-
Downloading file from SharePoint or any other cloud location it will be time consuming process if you choose Web service or any WCF service.
Solution-
Now Power Automate provides less code and quick solutions. Power Automate has all the connectors and Actions which help you to connect these cloud locations and process on the files.
Let’s see a scenario, I want to download a file on button click on my CRM Account form. The file is located in my account record Timeline Notes.
Let’s go step by step.
First of all, as this is action on click of button on form, we can choose “When Http Request Received” trigger in Power Automate. And in HTTP request we need record id i.e. accountid to retrieve specific Note attachment i.e. “CustomerInfoDoc”-
Now from above step we will get the Document – File name and Document body (base64) content.
So we need a variable to store files in array and another variable for document content-
Setting the variables from the Notes list which we got from “List rows” action-
We need to append array with below json-
{
“Name”: @{items(‘Apply_to_each’)?[‘filename’]},
“ContentBytes”: @{items(‘Apply_to_each’)?[‘documentbody’]}
}
We will use Name and ContentBytes in JavaScript Code which will be in the response of HttpRequest.
Now once file we got file content we need to send them in response-
We need the only file from Notes, In List Row action we can add row count =1, but still in response we can set formula in body first(variable(‘ContentArray’). As this is document in response add headers “Content-type”:”multipart/form-data”
Now our complete flow is ready and it looks like –
So now remaining part is calling the flow from button to download the file-
Add the below javascript and call “callPowerAutomateFlow” function on button click. Below is complete code for download –
function callPowerAutomateFlow(formContext) {
id = formContext.data.entity.getId().replace("{", "").replace("}", "");
var account = '{ "accountid": "' + id + '"'+ '}';
var flowUrl = "https://prod-04.centralindia.logic.azure.com:443/workflows/xxxxxxxxxxxxxxxxxxxxxxxxxx/triggers/manual/paths/invoke?api-version=2016-06-01&sp=%2Ftriggers%2Fmanual%2Frun&sv=1.0&sig=xxxxxxxxxxxx";
var req = new XMLHttpRequest();
req.open("POST", flowUrl, true);
req.setRequestHeader("Accept", "application/json");
req.setRequestHeader("Content-Type", "application/json; charset=utf-8");
req.onreadystatechange = function () {
if (this.readyState === 4) {
req.onreadystatechange = null;
if (this.status === 200) {
var result = JSON.parse(this.response);
var fileName = result.Name;
var fileCont = result.ContentBytes;
var filebyte = base64ToBufferArray(fileCont);
downloadFile(fileName, [filebyte]);
} else {
Xrm.Utility.alertDialog(this.responseText);
}
}
};
req.send(account);
}
function base64ToBufferArray(base64content) {
var binaryString = window.atob(base64content);
var binaryLen = binaryString.length;
var bytes = new Uint8Array(binaryLen);
for (var i = 0; i < binaryLen; i++) {
var ascii = binaryString.charCodeAt(i);
bytes[i] = ascii;
}
return bytes;
}
function downloadFile(name,data) {
var blob = new Blob(data, { type: "octet/stream" }),
url = window.URL.createObjectURL(blob);
if (window.navigator && window.navigator.msSaveOrOpenBlob) {
window.navigator.msSaveOrOpenBlob(blob, name);
} else {
const url = window.URL.createObjectURL(blob);
const a = document.createElement('a');
document.body.appendChild(a);
a.href = url;
a.download = name;
a.click();
window.URL.revokeObjectURL(url);
document.body.removeChild(a);
}
}
That’s it!! when I am clicking on Download button in CRM Account record, it is downloading my Attachment file from Notes which is with title “CustomerInfoDoc”.
Hope this will help…
Enjoy Ms CRM!!!
